Single LED Puck Light
Product Details
|
Description
|
Single LED Puck Light
|
|
Part #
|
MASTER_UCP-LED1
|
This LED puck light provides an even warm light that delivers enough illumination for any work surface or display, all while consuming less energy than their halogen equivalent. They provide task or accent illumination in residential and commercial indoor applications.
Finish Color
Color Temperature
Feature List
Puck Light
A 2 watt LED puck maintains a cool to the touch LED. The LEDs are rated for 50,000 hours. The opal glass shield provides for even lighting.
Light Output
This LED puck light is available in warm white (3000 K) or neutral white (4000 K) color temperature, providing 130 lumen output, 120° beam angle.
Linkability
Any two puck lights may be linked together with a maximum distance of 52". Up to five pucks from a 12V DC desktop driver (15W max) may be linked in-line (maximum distance from driver to last puck is 10m (33').
Mounting
These pucks can be surface mounted or recessed. Surface mounting is achieved with the included mounting ring (mounting hardware included), while recessed mounting is achieved with the pressure clips provided on the puck light.
Dimming
Dimmable when used with a dimming driver.
Operating Temperature
-20°C ~ 55°C (-4°F ~ 131°F).
Approvals
cULus listed.
Accessories
Please select a specific item to view its accessories
Specifications
| Wattage | Less than 5W |
| Finish Color | White, Black |
| Delivered Lumens | Up to 500 lm |
| Shape | Round |
| Beam Distribution | Wide (> 40°) |
| Color Temperature | 3000 K, 4000 K |
| Luminaire Type | Surface, Undercabinet/Millwork |
| Product Family | UCP |
Accessories
Please select a specific item to view its accessories
Product Features
Puck Light
A 2 watt LED puck maintains a cool to the touch LED. The LEDs are rated for 50,000 hours. The opal glass shield provides for even lighting.
Light Output
This LED puck light is available in warm white (3000 K) or neutral white (4000 K) color temperature, providing 130 lumen output, 120° beam angle.
Linkability
Any two puck lights may be linked together with a maximum distance of 52". Up to five pucks from a 12V DC desktop driver (15W max) may be linked in-line (maximum distance from driver to last puck is 10m (33').
Mounting
These pucks can be surface mounted or recessed. Surface mounting is achieved with the included mounting ring (mounting hardware included), while recessed mounting is achieved with the pressure clips provided on the puck light.
Dimming
Dimmable when used with a dimming driver.
Operating Temperature
-20°C ~ 55°C (-4°F ~ 131°F).
Approvals
cULus listed.
